Panasonic ECQ-F Film Capacitor 0.018UF 5% Tolerance, 630V.DC Lot 10 Pcs
Panasonic ECQ-F Film Capacitor 0.018UF 5% Tolerance, 630V.DC Lot 10 Pcs

Panasonic ECQ-F Film Capacitor 0.018UF 5% Tolerance, 630V.DC Lot 10 Pcs

Shipping calculated at checkout.

Product Description

The Panasonic ECQ-F Film Capacitor 0.033µF 630V ±5% (10 Pieces) is a high-quality component engineered for precision and reliability in electronic circuits. Designed with a metallized film construction, it offers a self-healing dielectric, low dissipation factor, and excellent stability under high-voltage conditions. With a capacitance of 0.033µF, rated voltage of 630V DC, and tight ±5% tolerance, this capacitor is ideal for demanding applications such as TV, amplifier, and radio repair, as well as general high-temperature electronic circuits.

Key Features

  • Brand: Panasonic
  • Series: ECQ-F
  • Type: Film Capacitor
  • Capacitance Rating: 0.033µF
  • Voltage Rating: 630V DC
  • Tolerance: ±5%
  • Lead Spacing: 10 mm
  • Mounting Style: Through-hole
  • Termination Style: Radial Leads, Solder Mount
  • Construction: Metallized Film, Self-Healing
  • Shape: Rectangular Film Body
  • Polarity: Non-polarized
  • Performance: Low dissipation factor, stable operation
  • Operating Temperature Range: –40 °C to +105 °C (typical for ECQ-F series)
  • Resistance Properties: High insulation resistance, low leakage current
  • Compliance: RoHS Compliant
  • Applications: TV, amplifier, radio repair, audio equipment, power supplies, general electronics
  • Quantity: 10 Pieces
